About TRU-ID

is the first true internal diameter hose designed specifically for combat firefighting with reduced water weight.

Technical details of TRU-ID

Scope

A Combat Classic Reborn From coast-to-coast, fire departments put out the call for an attack line that will deliver tried and true performance. A hose that will deliver targeted application rates with reduced kink, minimal nozzle whip and specific friction loss.

Jacket Construction

Ideal for Low Pressure Nozzles Unmatchable Kink Resistance Featuring True Robust Construction for Internal Diameters Superior Handling Less Water Weight Reduces Fatigue * A Combat Classic Reborn From coast-to-coast, fire departments put out.

Abrasion

The inside and outside jackets shall be manufactured with a minimum pick count of 9.5 picks per inch for increased strength and abrasion resistance.

Lining

The rubber lining shall be a single-ply extruded tube of synthetic EPDM compounded to resist ozone.

Couplings

Connection options are available to match apparatus and deployment preferences.

Performance and Standards

The minimum burst test pressure when tested in accordance to NFPA Hose manufactured to this specification shall be of superior quality and workmanship. 1961 on all TRU-ID hose shall be 1200 psi / 82 bar. Meets or exceeds NFPA 1961. UL listing applies by diameter and pressure rating.

Diameter specifications of TRU-ID

Diameter	Part No.	Service Test	Proof Test	Burst Test	Bowl Size	Weight Uncoupled
1.75"	DP17-TRU	400 psi	800 psi	1200 psi	2.125"	0.44 lbs/ft
2.25"	DP22-TRU	400 psi	800 psi	1200 psi	2.6875"	0.56 lbs/ft
2.50"	DP25-TRU	400 psi	800 psi	1200 psi	2.8125"	0.56 lbs/ft
