About Flame-Out

MSHA-approved mine hose with self-extinguishing properties and a heat- and cold-resistant jacketed rubber-lined construction.

Technical details of Flame-Out

Scope

Mine Safety and Health Administration approved, this lightweight jacketed and rubber lined fire hose features self-extinguishing properties and is guaranteed to meet the demands of underground fire fighting.

Jacket Construction

Extremely heat and cold resistant and available in single jacket or double with high quality polyester reinforced outer jacket and durable MSHA Approved rubber liner.

Abrasion

All polyester outer jackets provide superior cut, puncture and abrasion resistance while enhancing protection of a kink resistant rubber liner that guarantees reliable flow.

Lining

The filler yarns shall be constructed of high strength, low elongation, filament polyester to reduce weight and increase flexibility.

Couplings

Quality Internal expansion ring threaded couplings or as required by purchaser. The fire hose assembly supplied under this specification shall be constructed with superior quality and materials.

Performance and Standards

Curve and straight burst testing mistreatment that would render it unfit for service. Meets or exceeds NFPA 1961. UL listing applies by diameter and pressure rating.

Diameter specifications of Flame-Out

Diameter	Part No.	Service Test	Proof Test	Bowl Size	Weight Uncoupled
11/2"	SP15-MSHA	300 psi	600 psi	13/4"	0.23 lbs/ft
2"	SP20-MSHA	300 psi	600 psi	21/4"	0.33 lbs/ft
21/2"	SP25-MSHA	300 psi	600 psi	23/4"	0.39 lbs/ft
11/2"	DP15-MSHA	400 psi	800 psi	115/16"	0.38 lbs/ft
2"	DP20-MSHA	400 psi	800 psi	22/5"	0.46 lbs/ft
21/2"	DP25-MSHA	400 psi	800 psi	3"	0.64 lbs/ft
