About Eco-5

Lightweight single-jacket industrial hose combining polyester fibers with a thin-wall EPDM rubber liner and optional Key-Lok protection.

Technical details of Eco-5

Scope

Lightweight, single jacket construction, combining 100% polyester ring spun staple and filament fibers over a thin wall, high tensile, EPDM rubber liner.

Jacket Construction

The outer jacket is mildew resistant and available with “Key-Lok” polyurethane based polymer impregnation for unmatched abrasion and moisture resistance.

Abrasion

Hose assemblies shall be available with the special “Key-Lok” polyurethane based polymer impregnation for added abrasion resistance and ease in identification purposes. NFPA color options may be specified by the end user.

Lining

A proprietary reverse twill weave construction reduces friction loss, while high tensile yarn combinations allow hose to be 25% lighter.

Couplings

Connection options are available to match apparatus and deployment preferences.

Performance and Standards

Scope The service test pressure of hose made to this specification shall be specifications will have a potential service life and warranty of 5 years barring shall not elongate more than 48". Meets or exceeds NFPA 1961. UL listing applies by diameter and pressure rating.

Diameter specifications of Eco-5

Diameter	Part No.	Service Test	Proof Test	Bowl Size	Weight Uncoupled
1"	SP10-600	300 psi	600 psi	13/16"	0.10 lbs/ft
11/2"	SP15-600	300 psi	600 psi	13/4"	0.15 lbs/ft
2"	SP20-600	300 psi	600 psi	21/4"	0.17 lbs/ft
21/2"	SP25-600	300 psi	600 psi	23/4"	0.28 lbs/ft
