Ramfan Product Family

Tried and true conventional ventilators still earn their place on the rig, and the GF164SE is part of the gas-powered PPV line that helped build the RAMFAN name. It delivers dependable PPV performance in an economical, field-proven platform.

Quantitative details of GF164SE

Metric	Value
Weight	59 lbs / 27 kg
Runtime	Runtime 1 hr
Motor/Power	4.6 Hp
Blade/Impeller	Impeller 7-Blade
Noise	Noise 96.1 dB@3' (1 m)

Comparison with other Gas PPV Blowers

Product	Airflow	Power	Weight	Runtime
GF164SE	-	4.6 Hp	59 lbs / 27 kg	Runtime 1 hr
GF164GP	-	-	-	Runtime 1 hr
GF165	Opening Size 12,906 cfm	4.8 Hp	84 lbs / 38 kg	Runtime 2 hrs
GF210	30,039 m3/hr	4.8 Hp	88 lbs / 40 kg	Runtime 1 hr
GX200	puts out an impressive 12,800 cfm (21,760 m3/hr)	2.1 Hp	48 lbs / 22 kg	Runtime 1hr
