Specs Summary
Drawing PDF- Chassis: Enforcer
- Wheelbase: 271 in
- Engine: PACCAR MX-13, 510 hp, 1,850 lb-ft (EPA 2024) with integrated engine brake
- Transmission: Allison 4500 EVS 6-speed with external Modine cooler
- Cab: Enforcer 7010, raised-roof, insulated; 6 belted seats
- Water Tank: 300 gal UPF poly with 3" overflow
- Pump: Waterous S100 single-stage, 2,000 GPM, stationary pumping
- GVWR: 78,000 lb
- Front Axle/Suspension: Oshkosh TAK-4 non-drive 24,000 lb with KONI shocks
- Rear Axle/Suspension: Meritor RT52-185 tandem 54,000 lb; Air Link AL-520 air ride
- Tires (Front): Michelin XZY3 425/65R22.5 (20-ply)
- Tires (Rear): Michelin XDN2 12R22.5 (16-ply) tandem
