Specs Summary
Drawing PDF- Chassis: Enforcer Chassis
- Wheelbase: 245.75 WB
- Wheelbase: 229.5 in
- Engine: Cummins L9, 450 hp, 1,250 lb-ft (EPA 2024, with OBD)
- Transmission: Allison 3000 EVS (6th gen) with prognostics
- Front tires: Goodyear Armor MAX MSA, 425/65R22.50, 20-ply
- Rear axle: Dana S26-190, 27,000 lb (single rear axle)
- Rear tires: Goodyear Endurance RSA, 12R22.50
- Water tank: 500-gallon poly tank
- Pump: Waterous CSU, 2,000 GPM, single-stage
- GVWR: 49,800 lb
- Front axle/suspension: Oshkosh TAK-4 (non-drive), 22,800 lb
