Specs Summary
Drawing PDF- Chassis: 2024 Pierce Impel
- Engine: Cummins X12 500 HP
- Transmission: Allison 4000 EVS
- Rear Axle: Meritor RS-30-185, 31,000 lb
- Wheelbase: 220”
- Pump: Darley PSM 1500 GPM midship
- Foam System: FoamPro 2001 Class A
- Cab Configuration: 4-door, 10" raised roof
- Front Axle: Meritor MFS-23, 23,000 lb
- Overall Length: 33’ 6”
- Overall Height: 10’ 6”
- GVWR: 54,000 lb
