Specs Summary
Drawing PDF- Chassis: Pierce Arrow XT custom chassis
- Wheelbase: 256"
- Engine: Cummins X12 diesel
- Transmission: Allison 4000 EVS, 6-speed automatic
- Front Tires: Michelin XZY3, 425/65R22.5
- Rear Tires: Michelin X Works XDY, 315/80R22.5 (single axle)
- Cab: Arrow XT four-door raised roof (6720)
- Heavy Duty Rescue (HDR), non-walk-in aluminum body
- Build Location: Appleton, Wisconsin
- Compliance: NFPA 1901 (2016 edition, rescue classification)
- GVWR: 55,000 lbs
- Output: 500 hp / 1,700 lb-ft torque
