Specs Summary
Drawing PDF- Chassis: IMPEL
- Foam System: 30 GALLON FOAM CELL
- Wheelbase: 192.00 WB
- Body Style: Pumper, PUC, Aluminum
- Chassis: Impel Chassis, PUC-NG
- Cab: Cab, Impel FR, 7010 Raised Roof, PUC
- Engine: Engine, Cummins L9, 450 hp, 1250 lb-ft, with OBD, EPA 2024
- Front Suspension: Axle, Front, Oshkosh TAK-4, Non Drive, 19,500 lb
- Front Tires: Tires, Front, Michelin, XZY3 (wb), 425/65R22.50, 20 ply
- Pump: Pump, Pierce, 1500 GPM, Single Stage, PUC-NG
- Rear Axle: RS26185NFPF382-538 Axle, Rear, Meritor RS26-185, 27,000 lb
- Rear Tires: Tires, Rear, Michelin, XDN2, 12R22.50, 16 ply, Single
