X-Stream

The X-Stream line is broader than a single nozzle choice. Manual, hydraulic, electric, hazardous-location, and gas-mitigation versions all sit inside the same family. This page breaks them into a specification view that is easier to work with during apparatus design, industrial projects, and retrofit planning.

Family Snapshot

About X-Stream

Manual bodies

SM-1250B and SM-2000B use large handles for manual pattern adjustment and stay focused on traditional apparatus monitor setups.

Hydraulic actuation

SM-1250HB and SM-2000HB move pattern control to a hydraulic actuator while keeping the same primary flow bands.

Electric and hazardous

The BE-HL models support electronic pattern control, with hazardous-location approvals available for industrial work.

Gas mitigation

Gas-mitigation variants use a wide fog pattern package where vapor suppression, not reach alone, drives the selection.

Model Comparison

Flow Range	Control Format	Inlet
350 to 1250 gpm at 75 psi	Manual pattern control	2.5" or 3.5"
FM approved.
350 to 1250 gpm at 75 psi	Hydraulic actuator	2.5" or 3.5"
Remote stream-pattern control.
500 to 2000 gpm at 80 psi	Manual pattern control	3.5"
FM approved.
500 to 2000 gpm at 80 psi	Hydraulic actuator	3.5"
Remote stream-pattern control.
350 to 1250 gpm at 75 psi	Electronic motor	3.5"
FM approved or ATEX option.
500 to 2000 gpm at 80 psi	Electronic motor	3.5"
FM approved or ATEX option.
350 to 1250 gpm at 75 psi	Electronic motor	3.5"
Gas-mitigation fog application.
500 to 2000 gpm at 80 psi	Electronic motor	3.5"
Gas-mitigation fog application.

Where each subgroup fits

Manual models make sense when operators want direct local control and a simpler apparatus plumbing package.
Hydraulic variants help when pattern control has to move back to a remote operator position without changing the basic flow band.
Electronic hazardous-location models are aimed at industrial work where monitor/nozzle control and area classification both matter.
Gas-mitigation variants are for vapor control packages that need broad fog performance rather than straight-stream emphasis.

Selection Notes

The primary split in this family is the flow band: 350-1250 gpm or 500-2000 gpm.
The second split is control method: manual handles, hydraulic actuator, or electric motor.
The third split is environment: standard apparatus use, hazardous location, or gas mitigation.
That structure is why X-Stream usually needs a full package discussion instead of a one-line model callout.
