Firematic B.R.A.T.
The Rally 1000 platform repackaged as a compact mini pumper with real midship flow.
The Mini Pumper uses the Rally 1000 platform to combine a compact profile with the water power of a 1,000 GPM-class pump package. It is the right fit when departments need stronger suppression performance without moving up to a full-size engine.
| Applications | Serious off-road response, brush truck, severe weather |
|---|---|
| Available Chassis | Ford F-550, Dodge 4500 |
| GVW | Up to 19,500 lb |
| Seating Capacity | Up to 5 |
| Height Range | Up to 8' |
| Width Range | 90" to 96" |
| Engine | 6.7L 300 HP diesel |
| Wheels/Tires | Firematic super single wheels and Founders MT tires |
| Flat Bed | Lightweight aluminum flat bed with roll bar |
| Tank | Up to 400-gallon Pro Poly water tank |
| Pump | 1,000 or 1,250 GPM Hale midship pump with dual 6-inch intakes |
| Pump & Roll | Available as an option |
| Foam System | Class A or B injection |
| Reels | 1 or 2 Hannay aluminum booster reels with 200' of 1" hose |
| Hose Load | 800' of 5" deadlay |
| Air Compressor | 12-volt compressor with 5-gallon reservoir |
Product Pairing Note
This page uses the Wareham FD apparatus as a representative example for the Mini Pumper family while the spec table defines the broader product line.
Review the product information, then jump into archived delivery galleries to see how this B.R.A.T. family has been configured for real departments.
