MSA GAS DETECTION
MSA ALTAIR io Dock
Automated bump testing and calibration dock built around ALTAIR io 4 and ALTAIR io 6 compliance workflows.
Product Profile
The ALTAIR io Dock is the compliance and calibration station for the ALTAIR io 4 and ALTAIR io 6 product family. It automates bump testing and calibration while moving detector status and reporting into the MSA Grid cloud workflow.
The dock is built to simplify setup, reduce messy gas tubing, and give crews a bank-level view of gas cylinder status, stand activity, and current test state.
Dock Highlights
Detector support
Built to work with ALTAIR io 4 and ALTAIR io 6 instruments.
Bank size
A test bank can include up to three cylinder holders and ten test stands.
Testing workflow
Supports bump-only, calibration-only, bump with calibration on failure, and smart-mode testing.
Cylinder handling
Gas cylinders can be RFID-enabled or manually configured for the bank.
Status indication
Cylinder holder LEDs indicate low, empty, or expired gas; displays show bank and stand status.
Compliance reporting
Reporting can be sent to the cloud-based MSA Grid account without separate networking setup at the dock.
Part Number Groups
Dock assemblies
Dock assemblies and test stands are listed under the core ALTAIR io Dock group.
Cylinder holders
Cylinder holder options are offered as separate configurable pieces within the dock ecosystem.
Fresh air and filters
Fresh-air filter assemblies and replacement filter items are listed as dock service parts.
Spare parts
Spare-parts kits, front housing packages, and power accessories round out the dock support items.
ALTAIR io Dock Documents
Bump Testing White Paper
Gas Detectors for the Fire Service
US / Canada Approval Notes
No dedicated US or Canada approval PDF is shown for the ALTAIR io Dock, so this page does not display non-North-American approval documents.
